DECLARATION OF CONFORMITY
UK Declaration of Conformity
Tthe products 20V Cable Clip Gun, Battery Pack & Charger Model number: VSE-20-P01, VBP-20-20H, VBC-204 are in conformity with the following UK Directives if applicable.
S.I. 2008/1597 (as amended)
S.I. 2016/1091 (as amended)
S.I. 2016/1101 (as amended)
S.I. 2012/3032 (as amended)
And the harmonized standards
BS EN 60745-1:2009+A11:2010
BS EN 60745-2-16:2010
BS EN 55014-1:2021
BS EN 55014-2:2021
BS EN IEC 63000:2018
EU Declaration of Conformity
The products 20V Cable Clip Gun, Battery Pack & Charger Model number: VSE-20-P01, VBP-20-20H, VBC-204 are in conformity with the following European Directives if applicable.
2006/42/EC
2014/30/EU
2014/35/EU
2011/65/EU & (EU) 2015/863
And the harmonized standards
EN 60745-1:2009+A11:2010
EN 60745-2-16:2010
EN 55014-1:2021
EN 55014-2:2021
EN 60335-1:2010+A1:2013+A2:2016
EN 60335-2-29:2016+A1:2019
EN 61000-3-2:2019
EN 61000-3-3:2013+A1:2019
TECHNICAL DATA
20V CABLE CLIP GUN
VSE-20-P01
Rated Voltage : 20V d.c.
Rated Operation : Up to 60 fires/min
Magazine Shaft Capacity : 27 pcs
Weight (without charger) : 2.2kg
Noise Emission Value
Noise measurement value determined in accordance with EN 60745-2-16
LPA : 80.5dB(A)
Uncertainty K :3dB(A)
LWA : 91.5dB(A)
Uncertainty K : 3dB(A)
Vibration emission value
Vibration value determined in accordance with EN 60745-2-16
ah : 2.69 m/s2
Uncertainty K : 1.5 m/s2
